222                              Air Balance Jib Lifters
       GANTRY AND JIB CRANES                 materials. Effortlessly handle materials in a three dimensional work space. The push-button


                                             These lifters achieve high performance, excellent safety, and low cost in the handling of heavy
                                             hand control operates the pneumatic cylinder, raising and lowering the cable, in turn,
                                             positioning the load.  Arm rotation is 360°. Air pressure 100 psi.

                                                                                                  UNIFORM
                                                MODEL
                                                                                       MAXIMUM
                                                                            UP/DOWN
                                                                                                           WEIGHT
                                                NUMBER
                                                                            STROKE
                                                             DESCRIPTION
                                                                                      ARM LENGTH
                                                                                                           (POUND)
                                                                                                 CAPACITY
                                              DSJ-300
                                                                             57½"
                                                           FLOOR MOUNT
                                                                                                            647
                                                                                        93"
                                                                                                  250 lb.
                                              DSL-300
                                                                                                  250 lb.
                                                           FLOOR MOUNT
                                                                                                            697
                                                                             47¼"
                                                                                        78¼"
                                              DSC-300
                                                           FLOOR MOUNT
                                                                                                            823
                                              DSJ-300-P
            model DSJ-300
                                                                                        93"
                                                                                                  250 lb.
                                                             PORTABLE
                                                                             57½"
                                              DSL-300-P
                                                                                                           1087
                                                                             47¼"
                                                                                                  250 lb.
                                                             PORTABLE
                                                                                        78¼"
                                              DSC-300-P
                                                                                        86½"
                                                             PORTABLE
                                                                                                  350 lb.
                                                                                                           1219
                                                                             78¾"
                                              DSJ-300-C   CEILING MOUNT      78¾"       86½"      350 lb.  1043
                                                                                                            471
                                                                                        93"
                                                                             57½"
                                                                                                  250 lb.
                                              DSL-300-C   CEILING MOUNT      47¼"       78¼"      250 lb.   515
                                              DSC-300-C   CEILING MOUNT      78¾"       86½"      350 lb.   647
                                 model DSL-300-P  COILED HOSE FOR HAND CONTROL model DSJ-300-CH
                                             Power Lift Jib Cranes     12V DC & 115V 1-PHASE AC STANDARD
                  A                     B
                                             Designed for material handling applications on docks, in warehouses, or in truck beds. Choose
                                             either 12V DC, 1 HP with 6' long non-removable pendant control or 115V AC, 1/3 HP with
                                             fingertip switch to raise and lower hook. Powered winches are designed for intermediate lifting.
                                             Meets ANSI and OSHA specifications. 12" x 12" mounting plate. Unit is designed for vertical
                                             lifting only.  Do not use unit for lifting personnel or overhead lifting. Battery not included.
                                             Models with suffix -CSA feature a winch that meets Canadian requirements.
                                             A) Structural Jib Cranes feature rotation hand brakes that offer unlimited 360° manual
                                             positioning. Mast mounts permanently. Boom adjusts in 12" increments and can be positioned
                                             at 4 elevations. DC models include 46' of 3/16" aircraft-grade wire rope with swivel hook and
                                             safety latch. AC units feature 25' of 7/32" cable. Folds for storage.  Blue painted finish.
                  C                D
                                             B) The economical answer to your material handling problems. Offers light-duty, intermittent
                                             use. Up to 1,500 pound uniform capacity at 36" boom extension. 360° locking manual rotation,
                                             25' of 7/32" cable with hook on AC units.  46' of 3/16" cable on DC units. Blue painted finish.
                                             C) These cranes offer the same features as the Type A cranes with a galvanized finish.
                    CA Residents see
                   WARNING A, Pg. 459        D) These cranes offer the same features as the Type B cranes with a galvanized finish.
                            MODEL                          UNIFORM          BOOM             BOOM         WEIGHT
              ITEM         NUMBER           OPERATION      CAPACITY         REACH            HEIGHT       (POUND)
               A    WTJ-20-3-DC�             12V DC        2,000 lb.     39¼" to 63¼"     59 /16" to 96 /8"  261
                                                                                            9
                                                                                                  1
               A    WTJ-20-4-DC�             12V DC        2,000 lb.     51¼" to 87¼"     59 /2" to 106 /2"  260
                                                                                           1
                                                                                                  1
               A    WTJ-20-3-AC�             115V AC       2,000 lb.     39¼" to 63¼"     59 /16" to 96 /8"  280
                                                                                            9
                                                                                                  1
               A    WTJ-20-3-AC-CSA          115V AC       2,000 lb.      40" to 63"      54½" to 88½"     280
               A    WTJ-20-4-AC�             115V AC       2,000 lb.     51¼" to 87¼"     59 /2" to 106 /2"  290
                                                                                                  1
                                                                                           1
               A    WTJ-20-4-AC-CSA          115V AC       2,000 lb.      52" to 87"       54 /2" to 99"   290
                                                                                             1
               B    WTJ-E-15-3-DC�           12V DC        1,500 lb.     43 /16" to 66¾"  47 /8" to 73 /16"  213
                                                                           1
                                                                                                  5
                                                                                            1
               B    WTJ-E-15-3-AC�           115V AC       1,500 lb.     43 /16" to 66¾"  47 /8" to 73 /16"  223
                                                                                                  5
                                                                                            1
                                                                           1
               B    WTJ-E-15-3-AC-CSA        115V AC       1,500 lb.      42" to 66"      41½" to 65½"     223
               C    WTJ-20-3-DC-GAL          12V DC        2,000 lb.     39¼" to 63¼"     59 /16" to 95¾"  265
                                                                                            5
               C    WTJ-20-4-DC-GAL�         12V DC        2,000 lb.     51¼" to 87¼"     59½" to 106½"    266
               C    WTJ-20-3-AC-GAL          115V AC       2,000 lb.     39¼" to 63¼"     59 /16" to 95¾"  284
                                                                                            5
               C    WTJ-20-3-AC-CSA-GAL      115V AC       2,000 lb.     39½" to 63½"     59 /16" to 95¾"  284
                                                                                            5
               C    WTJ-20-4-AC-GAL�         115V AC       2,000 lb.     51¼" to 87¼"     59 /16" to 106"  281
                                                                                            5
               C    WTJ-20-4-AC-CSA-GAL      115V AC       2,000 lb.     51½" to 87½"    59 /16" to 106 /8"  281
                                                                                                   1
                                                                                           5
               D    WTJ-E-15-3-DC-GAL�       12V DC        1,500 lb.      43" to 66"       47" to 73 /16"  213
                                                                                                 3
               D    WTJ-E-15-3-AC-GAL�       115V AC       1,500 lb.     43 /16" to 66¾"  47 /8" to 73 /13"  223
                                                                                                  5
                                                                           1
                                                                                            1
               D    WTJ-E-15-3-AC-CSA-GA     115V AC       1,500 lb.     43 /16" to 66¾"   47" to 73 /16"  223
                                                                                                 3
                                                                           1
                          WINCH-AC-HHPB        UPGRADE AC WINCH WITH HANDHELD PUSH BUTTON CONTROL           5
                                                  (THIS OPTION REPLACES STANDARD FINGERTIP SWITCH ON AC WINCHES)
