226                            Hand Winches
       GANTRY AND JIB CRANES  WARNING A, Pg. 459  WALL-S  loads.  Constructed of steel worm gear drives with zinc plated finish.  Pinion gear shaft with lubricated


                                           Wall Mounted Hand Winches Pulling devices that use a wire, rope, cable, strap or web to move heavy
               CA Residents see
                                           down bushings provide smooth operation and long life.
                                    model
                                           Stainless Steel Hand Winches are constructed of 304 stainless steel for corrosion resistance.  Machine-
                                           cut spur gears ensure smooth accurate operation, while protective gear covers keep dirt out and
                                           help prevent worker injuries.  Winches feature a drum clamp for easy attachment of wire rope (not
                                           included), and an automatic brake for positive load control during lifting and lowering operations.

                                                                        UNIFORM
                                                                                    GEAR
                                                                                                         WEIGHT
                                                 MODEL
                                                                                              LENGTH
                                                NUMBER
                                                                        CAPACITY
                                                              TYPE
                model WALL-D
                                                                                                5
                                                                                    41:1
                                                                                               9 /8"
                                                             SINGLE
                                                                                                          12
                                            WALL-S�
                                                                                                5
                                            WALL-D�
                                                                                                          13
                                                                                    41:1
                                                                                               6 /8"
                                                                        1,500 lb.
                                            STAINLESS STEEL  DOUBLE     1,500 lb.   RATIO     HANDLE     (POUND)
                                            HWSS-1200-NR�    SINGLE     1,200 lb.   4.2:1      8¼"         9
                                            HWSS-1800-NR�    SINGLE     1,800 lb.    5:1       12½"       18
                                    model   HWSS-2600-NR�    SINGLE     2,600 lb.   10:1       12½"       24
                               HWSS-1800-NR
                                            Manual and Worm Gear Hand Winches
                                            Manual Hand-Operated Gear Drive Winch, model HWG-600, is designed for many lifting,
                                            lowering, and pulling applications.  Equipped with a load pressure brake.  This brake holds the
                                            load at any required height during hoisting and lowering and prevents any unintentional lowering
                                            of the load.  Adjustable crank handle for fast lifting of smaller loads, resulting in lowest possible
                               model HWG-600
                                            handle effort and rapid winding of the rope.  All rotating parts are maintenance-free.  Suitable for
                                            operation in ambient temperatures of 14° through 120°F.  Capacity 600 pounds.
                                            Worm Gear Hand Winch, model HWV-1000, allows for better load control and features a
                                            reinforced frame comfort-grip handle.  Worm gear provides load holding capability when handle
                                            is released.  Reel stops automatically, locking load in place whenever the handle is released.  High
                                            quality enamel paint finish, dipped and baked.  Crank handle can be adjusted in length.  Winch
                                            housing and rope drum are made from robust steel plate.  Capacity 1,000 pounds.
                                               MODEL                 WIRE     DRUM        OVERALL SIZE   WEIGHT
                                              NUMBER     GEAR TYPE   ROPE   CAPACITY (FT.)  (L x W x H)  (POUND)
                                                                                             7
                                                                                                  7
                                            HWG-600�     MANUAL     3/16"      65       9½" x 7 /8" x 7 /8"  36
            model HWV-1000                  HWV-1000�    WORM        1/4"      45        7" x 10¼" x 7"    35
                                           CABLE IS NOT INCLUDED
                                           Galvanized Two-Speed Cable Puller
                                           Great for use in horizontal pulling applications such as positioning equipment, stringing lines,
                                           and emergencies. Can be used in both single and double-line pulling applications. Handle
                                           ratchets to take up cable. When handle is rotated all the way back, the cable reel will free-spool.
                                           Handle length is 30". Minimum headroom is 24". Single-line cable length is ¼" x 120" (cable
                                           length is 60" when used as a double-line). Not for use in vertical lifting applications.
               GALVANIZED TWO-SPEED            MODEL       SINGLE-LINE      DOUBLE-LINE     SINGLE-LINE   WEIGHT
                  CABLE PULLER
                  model CABLE-P4               NUMBER    UNIFORM CAPACITY  UNIFORM CAPACITY  CABLE LENGTH  (POUND)
                                            CABLE-P4�       2,000 lb.       4,000  lb.       ¼" x 120"      14
                    CA Residents see
                   WARNING A, Pg. 459
                                           Long Reach Cable Pullers

                                           Cable Pullers are ideal for applications requiring pulling over long distances. Pull up to 60'
                                           without unhooking and resetting as required when using conventional lever or hand chain hoists.
                                           Works great for pulling horizontally. Not for use in vertical lifting applications.

                                               MODEL       UNIFORM    USABLE CABLE LENGTH IN   CABLE DIAMETER  WEIGHT
                                              NUMBER       CAPACITY        FEET  (~m)     (APPROXIMATE)  (POUND)
                                            CP-15�         1,500 lb.         60               5 /16"       36
                model CP-30                 CP-30�         3,000 lb.         60               7 /16"       64
                                           *MEETS CSIR FOR USE IN MINING INDUSTRY
