212                             Professional Hand Chain Hoists
       GANTRY AND JIB CRANES                allow installation in confined areas.  Heat-treated spur gear efficiently designed to provide smooth


                                            These lightweight hoists are durable and easy to operate.  Compact design and low headroom
                                            load handling and low hand chain pull.  Reinforced double pawl brake system and larger diameter
                                            pawl springs ensure reliable braking.  Designed with a safety factor 4 times the rated capacity.
                                            Individually tested at 150% of the rated capacity.  Features lightweight, high strength grade 100
                                            alloy steel load chain 25% stronger than grade 80 chain, galvanized pull chain, and forged steel
                                            upper and lower hooks with safety latches.  Meets ANSI B30.16-2003 requirements.
                                                MODEL
                                                                                                         WEIGHT
                                                              UNIFORM
                                                                               LIFT
                                                                                            HEADROOM
                                                              CAPACITY
                                                NUMBER
                                                                                                           27
                                                                               10
                                                                                             11¼"
                                             PHCH-1-10�
                                                                                                           35
                                                              1,000 lb.
                                                                               15
                                                                                             11¼"
                                             PHCH-1-15�
                                                                                             11¼"
                                             PHCH-1-20�
                                                                                                           39
                                                              1,000 lb.
                                                                               20
                                                                                               7
                                                                                                           34
                                             PHCH-2-10�       1,000 lb.       (FEET)         (INCHES)    (POUND)
                                                                                             12 /16"
                                                                               10
                                                              2,000 lb.
                 model                                                                         7
                PHCH-1-10                    PHCH-2-15�       2,000 lb.        15            12 /16"       39
                                                                                               7
                                             PHCH-2-20�       2,000 lb.        20            12 /16"       46
                                                                                               3
                                             PHCH-3-10�       3,000 lb.        10            13 /8"        39
                                                                                               3
                                             PHCH-3-15�       3,000 lb.        15            13 /8"        45
                                                                                               3
                                             PHCH-3-20�       3,000 lb.        20            13 /8"        51
                                             PHCH-4-10�       4,000 lb.        10             15 "         41
                                             PHCH-4-15�       4,000 lb.        15             15 "         48
                                             PHCH-4-20�       4,000 lb.        20             15 "         53
                                 model                        6,000 lb.        10            18¾"          56
                  CA Residents see  PHCH-3-10  PHCH-6-10�
                WARNING A, Pg. 459
                                             PHCH-6-15�       6,000 lb.        15            18¾"          62
                                             PHCH-6-20�       6,000 lb.        20            18¾"          70
                                                                                               5
                                             PHCH-10-10�     10,000 lb.        10            23 /8"       111
                                                                                               5
                                             PHCH-10-15�     10,000 lb.        15            23 /8"       114
                                                                                               5
                                             PHCH-10-20�     10,000 lb.        20            23 /8"       125
                                            Hand Chain Hoists
                                            These lightweight hoists feature enclosed double ratchet pawls with self adjusting disc brake and
                                            a safety factor 4 times the rated capacity. Tested at 150% of the rated capacity.  Features grade 80
                                            black chain tempered to ISO 3077, galvanized pull chain, hardened two-stage gears, and forged
                                            steel upper and lower hooks with safety latches. Meets ANSI B30.16-2003 requirements.
                                                MODEL        UNIFORM          LIFT         HEADROOM      WEIGHT
                                               NUMBER        CAPACITY        (FEET)        (INCHES)      (POUND)
                                             HCH-1-10�      1,000 lb.         10             11"          24
                                             HCH-1-15�      1,000 lb.         15             11"          28
                            HAND CHAIN HOISTS  HCH-1-20�    1,000 lb.         20             11"          32
                               series HCH
                                             HCH-2-10�      2,000 lb.         10             12"          26
                                             HCH-2-15�      2,000 lb.         15             12"          32
                                             HCH-2-20�      2,000 lb.         20             12"          37
                                CA Residents see
                               WARNING A, Pg. 459  HCH-3-10�  3,000 lb.       10             15"          43
                                             HCH-3-15�      3,000 lb.         15             15"          49
                                             HCH-3-20�      3,000 lb.         20             15"          99
                                             HCH-4-10�      4,000 lb.         10            17½"          48
                                             HCH-4-15�      4,000 lb.         15            17½"          54
                                             HCH-4-20�      4,000 lb.         20            17½"          117
                                             HCH-6-10�      6,000 lb.         10             19"          59
                                             HCH-6-15�      6,000 lb.         15             19"          64
                                             HCH-6-20�      6,000 lb.         20             19"          132
                                             HCH-10-10�     10,000 lb.        10             21"          111
                                             HCH-10-15�     10,000 lb.        15             21"          117
                                             HCH-10-20�     10,000 lb.        20             21"          176
                                            Non-Sparking Chain Hoists
                                            Non-sparking brass construction. Brake engages automatically as soon as the hand chain stops
                                            moving.  Forged load hooks.  Low gear ratio reduces effort required for lifting.  Satisfies relevant
                                            ANSI B30.16-2003 requirements.
                  model
                HCH-NS-1-10
                                                  MODEL         UNIFORM        LIFT          HEAD        WEIGHT
                                                 NUMBER        CAPACITY        (FEET)        ROOM        (POUND)
                                              HCH-NS-1-10�     1,000 lbs.       10            14"          35
                 CA Residents see
                WARNING A, Pg. 459            HCH-NS-2-10 �    2,000 lbs.       10            14"          47
