210                             Quick Install Manual Trollies
       GANTRY AND JIB CRANES   model QIT-2  virtually any S, H, W, and M type I-beam. Width is adjusted with manual screw mechanism.


                                            These trollies are dependable, safe, and easy to use. Designed to easily adjust to the width of
                                            Includes locking ring to prevent trolley width from changing accidentally. Manual screw mechanism
                                            may also be tightened to prevent trolley from moving (similar to a Beam Clamp). Each trolley
                                            includes four (4) rollers with sealed bearings for long life.  A lifting eye is located at the bottom of
                                            the trolley for attaching a hoist (not included).  Steel construction and painted finish.
                                                                                                          WEIGHT
                                                           FITS I-BEAM
                                               MODEL
                                                                                             UNIFORM
                                                          FLANGE WIDTH
                                                                            HEADROOM
                                               NUMBER
                                                                                                          (POUND)
                                                                                            CAPACITY
                                                            3" to 5"
                                             QIT-03�
                                                                                              300 lb.
                                                            3" to 5"
                                                                              6¾"
                                             QIT-06�
                                                                                                           13
                                                                                              600 lb.
                                                            3" to 5"
                                                                                                           13
                                             QIT-1�
                                                                              6¾"
               model QIT-6
                                                                                                           14
                                                                                            2,000 lb.
                                                                              8 /8"
                                                            3" to 5"
                                                                              1
                                             QIT-2�
                                                                                                           17
                                                                              10"
                                                                                            4,000 lb.
                                             QIT-4�         3" to 7½"         6¾"           1,000 lb.      13
                                                                               3
                                             QIT-6�         3" to 7½"        10 /8"         6,000 lb.      40
                                             QIT-8�        4" to 11¾"        13 /8"         8,000 lb.      68
                                                                               7
                                                                               7
                                             QIT-10�       4" to 11¾"        13 /8"         10,000 lb.     68
                                                                               7
                                             QIT-12�       4" to 11¾"        13 /8"         12,000 lb.     70
                                            Low Profile Manual Trollies
                                            These trollies have been designed to quickly install on virtually any S, H, W, and M type I-beam.
                                            The width of the trolley is adjusted by rotating the center rod with lifting eye clockwise or
                                            counterclockwise. Once hoist is attached, center rod cannot be rotated which prevents trolley width
                                            from accidentally changing. The trolley includes four (4) rollers with sealed bearings. Choose either
                                            push or geared trolley. Geared trolley is ideal for use when precise positioning is required. A lifting
                   PUSH LOW PROFILE
                  EYE MANUAL TROLLEY        eye is located at the bottom of the trolley for attaching a hoist (sold separately). Steel construction
                     model E-MT-4           and painted finish. Headroom is measured from bottom of wheel to bottom of hooking eye.
                                               MODEL                   I-BEAM                  UNIFORM    WEIGHT
                                               NUMBER    DESCRIPTION   FLANGE     HEADROOM     CAPACITY   (POUND)
                                             E-MT-1�       PUSH       2" to 8 /8"   2 /2"      1,000 lb.   12
                                                                           5
                                                                                     1
                                                                                     5
                                                                      1
                                                                            1
                                             E-MT-2�       PUSH      2 /2" to 10 /8"  2 /8"    2,000 lb.   20
                                             E-MT-4�       PUSH      2 /2" to 8 /8"  3"        4,000 lb.   31
                                                                            5
                                                                      1
                                                                           5
                                                                                     3
                                             E-MT-6�       PUSH       3" to 8 /8"   3 /8"      6,000 lb.   52
                                             E-MT-8�       PUSH        3" to 9"      4"        8,000 lb.   82
                                             E-MT-10�      PUSH        3" to 9"      4"       10,000 lb.   82
                                                                                     1
                                                                            1
                                                                      1
                                             E-MT-1-C�    GEARED     2 /2" to 5 /2"  4 /2"     1,000 lb.   21
                                                                            1
                                                                      1
                                             E-MT-2-C�    GEARED     2 /2" to 5 /2"  5"        2,000 lb.   29
                                             E-MT-4-C�    GEARED      3" to 6 /2"    6"        4,000 lb.   41
                                                                           1
                                                                                     3
                                             E-MT-6-C�    GEARED       3" to 8"     7 /8"      6,000 lb.   62
                  GEARED LOW PROFILE         E-MT-8-C�    GEARED       3" to 9"     8 /8"      8,000 lb.   100
                                                                                     5
                  EYE MANUAL TROLLEY         E-MT-10-C�   GEARED       3" to 9"     8 /8"     10,000 lb.   103
                                                                                     5
                (FEATURES 10 FT. OF CHAIN)
                    model E-MT-2-C
                                            Low Headroom Combination Chain Hoist/Trolley
                                            Use this to gain additional raised hook height.  Chain hoist hook travel is 10 feet.
                                            Assembly required.  Fits on wide flange or S-type I-beam.
                                               MODEL               BOTTOM OF ROLLER  I-BEAM     UNIFORM    WEIGHT
                                              NUMBER    DESCRIPTION  TO TOP OF HOOK  FLANGE     CAPACITY  (POUND)
                                             LOW-1P�      PUSH         11¾"         2" - 6"      1,000 lb.  45
                                             LOW-2P�      PUSH          13"         2½" - 8"     2,000 lb.  63
                                             LOW-4P�      PUSH         16¼"         3½" - 8"     4,000 lb.  92
                                             LOW-6P�      PUSH         18¼"         4" - 8"      6,000 lb.  144
                                             LOW-1G�     GEARED        11¾"         2" - 6"      1,000 lb.  49
                                             LOW-2G�     GEARED         13"         2½" - 8"     2,000 lb.  73
                                             LOW-4G�     GEARED        16¼"         3½" - 8"     4,000 lb.  110
                                             LOW-6G�     GEARED        18¼"         4" - 8"      6,000 lb.  158
                                            Compact & Lightweight Lever Hoist (disc brake)
                 New                        Compact and Lightweight Lever Hoists are ideal for use in confined areas when fastening, fixing
                                            or positioning of light load is required.  High impact aluminum alloy housing with all the main
                                            parts made of heat treated alloy steel (more durable and longer life).  Advanced gear reduction
                                            system (5 gears in the gear box) enables effortless handling and requires low hand-pull force for
                                            highly reliable lifting.  Withstand 1500 cycles with 110% of rated capacity.  Features lightweight
                                            high strength grade 100 chain.  Heavy duty storage bag included.
                                                MODEL      UNIFORM     STANDARD   MINIMUM DISTANCE   HANDLE  WEIGHT
              model VKX-05-5
                                               NUMBER      CAPACITY    LIFT (FEET)  BETWEEN HOOKS  LENGTH  (POUND)
                                                                                       7
                                                                                                   3
                                             VKX-05-5�      500 lb.       5           7 /8"       5 /4"     6
                                                                                                   1
                                                                                       7
                                             VKX-10-5�    1,000 lb.       5           9 /8"       6 /4"     8
