95

           NARROW SCISSOR LIFT TABLES
                MODEL      PLATFORM  LOWERED  RAISED  *UNIFORM  VOLTAGE  WEIGHT
               NUMBER     SIZE (W x L)  HEIGHT  HEIGHT  CAPACITY  PHASE  (POUND)
           EHLT-N-1648-1-32  16" x 48"  8"   32"    1,000   460/3  359
           EHLT-N-1648-2-32  16" x 48"  8"   32"    2,000   460/3  364          model
          *UNIFORM STATIC CAPACITY / EXTERNAL POWER UNIT                        EHLT-N-1648-2-32                   ERGONOMIC SOLUTIONS

          Radio Remote Control

          Put the power in your hands with the Radio Remote Control. This lightweight, two-
          button, remote control gives you the freedom to control your scissor table from a range
          up to 150 feet. Unit is also available in a four-button model for lift and tilt tables. The
          remote control is 4" wide x 6" high x 2" thick.
          Approved to meet part 15 of the Federal Communications Code. Designed to prevent
          crosstalk and false triggering from stray radio frequency.
          Model RRC-2PB works with model series: EHLT, HDD, EM1, TL-100-F, and HBD.
          Model RRC-4PB works with model series: EHLTT, ZLTT, and HLD.
             MODEL                                                WEIGHT
             NUMBER                   DESCRIPTION                 (POUND)
           RRC-2PB      2-BUTTON SYSTEM (LIFT-HOLD-LOWER CIRCUIT)   1
           RRC-4PB      4-BUTTON SYSTEM (LIFT AND TILT CIRCUIT)     1
          RETROFIT AVAILABLE - CONTACT FACTORY STANDARD

          Integral Scale for Scissor Tables
          •  Validate number of pieces or parts
          •  Know exactly how much weight is on your table            New
          •  Bolt-on corner retainers
          •  No holes or bolting required
          •  Installs and removes in seconds
          •  Expedite your shipping & palletizing process
          •  Available in 36" x 36", 48" x 48", and 48" x 60" platform tops
            (rests on top of table)
          •  Adds approximately 3½" to overall height                INTEGRAL SCALE
          •  Scale functions: zero weight and tare weight            model EHLT-SCALE
          •  Weighing units: pounds or kilograms
          •  Indicator mounted on pedestal, 110VAC
          •  Scale capacity, maximum 5,000 lb.
          •  Scissor table not included, select next higher capacity scissor table
                MODEL                                             WEIGHT
               NUMBER                     USE WITH                (POUND)
           EHLT-SCALE     SERIES EHLT; LIFT TABLE                  295
           EHLTD-SCALE    SERIES EHLTD; DOUBLE LIFT TABLE          295
           EHLTS-SCALE    SERIES EHLTS; SHORTY LIFT TABLE          295             ABOVE ITEMS ON THIS PAGE ARE OPTIONS.
           EHLTSD-SCALE   SERIES EHLTSD; SHORTY DOUBLE LIFT TABLE  295               SCISSOR TABLE SOLD SEPARATELY
           PST-SCALE      SERIES PST; PORTABLE LIFT TABLE          295



          Programmable Height
          Eliminate unnecessary bending and "land control jogging" by presetting multiple working
          heights at the touch of a button
          •  Set height function: Programmable up to 4 preset heights
          •  Incremental height adjustment for jogging lift at preset increments
          •  Raise/lower push-button on the keypad                    New
          •  Fully integrated controller with LCD display
          •  A 15-button keypad on the panel display
          •  Excellent for repeat repositioning applications
          •  Hybrid technology linear sensor is used to control positions at any preset height
          •  Scissor Table not included
                 MODEL                                               WEIGHT
                 NUMBER                      USE WITH                (POUND)
           EHLT-PROGRAM      SERIES EHLT; LIFT TABLE                  295
           EHLTD-70-PROGRAM  SERIES EHLTD; DOUBLE LIFT TABLE (up to 70" lift height)  295
           EHLTS-PROGRAM     SERIES EHLTS; SHORTY LIFT TABLE          295
           EHLTSD-PROGRAM    SERIES EHLTSD; SHORTY DOUBLE LIFT TABLE  295             PROGRAMMABLE HEIGHT
           EHLTG-PROGRAM     SERIES EHLTG; GROUND LIFT TABLE          295                suffix PROGRAM
          MINIMUM DECK SIZE 30"W x 48"L
