INDUSTRIAL STORAGE SOLUTIONS
Horizontal Sheet Rack

Designed for storage of sheet goods and similar materials. Flat storage reduces warping of
thin materials. Five shelf design allows for generous storage of multiple thickness materials.
Distance between shelves is 9½". All welded steel frame allows for 2,000 pound uniform
capacity per shelf. Four sided access when using 4' x 8' sheet or smaller. Supplied with lag
down points.
model
SHEET-R-57 MODEL OVERALL SIZE NUMBER OF DISTANCE WEIGHT
NUMBER (W x L x H) SHELVES BETWEEN SHELVES (POUND)
SHEET-R-57� 54½" x 102¾" x 48" 5 9½" 514
AS-124-4PK� ANCHOR BOLTS FOR CONCRETE (4) ½" x 4" 4

Standard Sheet Rack
Designed for vertical, or horizontal, storage of sheet goods. Standard unit comes with four (4)
bays. Intermediate floor bracing gives added steel support, while keeping material off the floor.
Uniform capacity per bay is 1,500 pounds. Unit is supplied with lag down points. Baked-in
powder-coated toughness.

MODEL OVERALL SIZE NUMBER DISTANCE WEIGHT
model VSSR-15 NUMBER (W x L x H) OF BAYS BETWEEN BAYS (POUND)
VSSR-15� 50" x 84" x 44" 4 10" 290
AS-124-4PK� ANCHOR BOLTS FOR CONCRETE (4) ½" x 4" 4

Portable Storage U-Racks
model U-RACK-10 These Storage Racks can be stacked up to four units high. Easy to set up and tear down and
great for temporary locations. All welded steel construction for years of dependable service.
Maximum four (4) units high. Safety pins connect racks together. (Sold individually.)

MODEL OUTSIDE SIZE INSIDE DIMENSION UNIFORM WEIGHT
NUMBER (W x D x H) (W (bottom) x W (top) x H) CAPACITY/PAIR (POUND)
U-RACK-6� 25" x 4" x 19" 16" x 21½" x 15½" 6,000 lb. 31
U-RACK-10� 25" x 4½" x 19" 16" x 21½ x 18" 10,000 lb. 35

Variable Height Sheet Racks

Store various sizes of sheet goods in the vertical position for easy viewing of stock. These
sheet racks are perfect for use with multiple sizes of material. Four bays with different heights
increase visibility of stored material. Available in all welded steel construction, model VHSR-4
and VHSR-8, or bolt together construction, model VHSR-4B. Bolt-together units feature
adjustable-width uprights. Uniform capacity per bay is 1,500 pounds. Unit is supplied with
lag down points. Baked-in powder-coated toughness.

model VHSR-4
MODEL OVERALL SIZE NUMBER DISTANCE WEIGHT
NUMBER (W x D x H) OF BAYS BETWEEN BAYS (POUND)
3
7
VHSR-4� 47 /8" x 36" x 41¾" 4 6 /8" 170
VHSR-8 96" x 36" x 60" 4 6 /8" 268
7
VHSR-4B 47½" x 36" x 42" 4 6 /16" 178
9
AS-124-4PK� ANCHOR BOLTS FOR CONCRETE (4) ½" x 4" 4
Portable / Stackable Vertical Sheet Rack
The Vertical Sheet Rack supports multiple sizes of sheet material such as paneling, plywood,
drywall, or anything that is long, bulky, and hard to handle. Ideal for lumberyards and
hardware stores. Integral full length fork tubes standard for easy moving and handling with a
fork truck. Industrial welded steel construction with blue paint finish. Stack no more than two
units high. Uniform capacity is 4,000 pounds (2,500 pounds for second when stacked).

MODEL OVERALL SIZE USABLE STORAGE WEIGHT
NUMBER (W x L x H) BAY SIZE (W x H) (POUND)
SVSR-3260 32½" x 60" x 46" 16½" x 42" 355
Fork Pockets model SVSR-3260
