409

Linear Actuated Elevating Cart (partially stainless steel) 12V DC STANDARD
Transport materials from workstation to workstation with ease. Platform is raised and lowered with an
electric linear actuator for precise positioning. Linear actuator will not allow platform to drift down - a
common problem with hydraulic carts. This linear actuated cart is powered with a 12V DC battery and
features an on-board charger. Emergency stop button standard on hand control. Includes two (2) rigid
and two (2) swivel casters. Platform, handle, base frame, caster brackets and hardware are all stainless
steel. Air pump, hydraulic cylinder, scissor legs and foot pedal are zinc plated. Battery pack, charger, and STAINLESS STEEL & BRONZE
hand control are plastic. Linear actuator is plastic with a chrome-plated piston. Wheels are poly-on-poly.
MODEL PLATFORM UNIFORM LOWERED RAISED WEIGHT model
NUMBER SIZE (W x L) CAPACITY HEIGHT HEIGHT (POUND) CART-500-LA-PSS
CART-500-LA-PSS 19½" x 32" 500 lb. 15" 33" 248
Lift & Tilt Cart with Sequence Select (partially stainless steel)
Lift & Tilt Cart with Sequence Select has a unique design which allows the user to RAISE and TILT
materials to an ergonomic position for better posture and operator comfort. The manual hydraulic foot
pump controls the platform lift, lower, and tilt. A manual selector valve is used to control the lift/lower
sequence independently from the tilt sequence. The platform includes a 7" high retaining lip. Rolls on
two (2) rigid and two (2) swivel 5" poly casters.
MODEL PLATFORM UNIFORM MAX. SERVICE WEIGHT
NUMBER SIZE (W x L) CAPACITY TILT RANGE** (POUND)
CART-1000-LT-PSS* 22" x 33 /8" 1,000 lb. 40° 17½" to 35" 323 model
5
**SERVICE RANGE FIGURED WITH PLATFORM LEVEL CART-1000-LT-PSS
*PLATFORM, HANDLE, CASTER BRACKETS, & HARDWARE ARE ALL STAINLESS STEEL.
PUMP ASSEMBLY, SCISSOR LEGS, AND FOOT PEDAL ARE ZINC PLATED.
Low Profile Electric Lift Table 115 V 1-PHASE STANDARD
The open center on the "U" Type Electric Lift Tables, enable a pallet truck to place a load on the
platform. Units feature an external power pack equipped with a pressure relief valve that
prevents overloading and a flow control valve that controls the lowering speed. Remote
power pack comes complete with a cover to protect the motor from dust and debris. Raise
and lower the unit using the UP and DOWN push buttons on the 24V control box. Safety
features include electric toe guards, safety velocity fuse in cylinders, safety maintenance
props, and an emergency stop button on the control box. Inside width is 29¾" by 44¼"
long. Power supply is 115V single phase with pedestal mounted push buttons. Unit is 304 stainless
steel. All the components are stainless steel except electrical connections, control box and power unit. model EHU-12-SS
MODEL PLATFORM UNIFORM LOWERED RAISED WEIGHT
NUMBER SIZE (W x L) CAPACITY HEIGHT HEIGHT (POUND)
EHU-12-SS 50" x 59" 1,200 lb. 3 /8" 33½" 592
3
Spring Scissor Tables (partially stainless steel)
model
Spring Scissor Tables are ideal for distributing and shipping facilities. These units allow the user to SST-45-PSS-ST
transfer products from work space to work space, while holding an ergonomically friendly position.
The frame is designed of steel construction, which allows for strength and durability. The scissor
mechanism raises the unit to the desired height, while the internal spring provides support when unit
is being loaded and unloaded. The round top can be manually rotated 360° for improved packaging
and handling capabilities. Fork pockets measure 6¾"W x 1½"H. Constructed of partially stainless steel
base, frame, springs, and legs. Model SST-45-PSS-ST has a solid top.
model
MODEL PLATFORM UNIFORM SERVICE BASE SIZE WEIGHT SST-45-PSS
NUMBER DIAMETER CAPACITY RANGE (W x L) (POUND)
SST-45-PSS 43 /8" 400 to 4,500 lb. 9" to 27¾" 36" x 36¾" 432
5
SST-45-PSS-ST 43 /8" 400 to 4,500 lb. 9" to 27¾" 36" x 36¾" 452
5
Air Corner Tilter FACTORY AIR POWERED
A Stainless Steel Air Corner Tilter provides ergonomic loading and unloading of bulk containers,
gaylords, or crates. Pallet truck and fork truck accessible. Tilts up to 45°. Activated by a hand operated
control lever. The air bag inflates tilting the container automatically as it is unloaded. As the container
becomes lighter, it automatically tilts and the material shifts to the corner of the container where it can
be easily removed by manual or mechanical means. The regulator is factory preset to begin rotating the
container when the weight reaches approximately 900 pounds.

MODEL PLATFORM UNIFORM WEIGHT
NUMBER DESCRIPTION SIZE (W x L) CAPACITY (POUND) model AIR-THL-SS
AIR-THL-SS HAND LEVER OPERATION 44" x 44" 1,500 lb. 550
