       DRUM HANDLING EQUIPMENT & SPECIALTY CONTAINERS
                                            Automatic Eagle Beak™ Drum Lifters
                                    New     This time tested and proven design allows a fork truck operator to easily secure, move, and release
                                            drums without leaving the seat of the fork truck. For use with open and closed head (with lid
                                            installed and secured) 30 and 55 gallon plastic, steel, and fiber drums with a top lip strong enough
                                            to support the weight of the drum. Choose single-drum or double-drum configuration. Includes
                                            safety restraint to secure unit to the fork truck. Welded steel construction. Baked-in powder-coated
                                            toughness. Fork pockets measure 7½" wide x 2½" high usable on 20½" centers. A ratchet strap is
                                            supplied to secure the drum to the unit when traveling over rough terrain. FMDL-1 and FMDL-2
            model FMDL-1
                                            meet OSHA 1910-178 requirements.
                                                 MODEL        NUMBER        UNIFORM        OVERALL SIZE   WEIGHT
                                                 NUMBER       OF DRUMS      CAPACITY        (W x L x H)   (POUND)
                                                                                               5
                                             FMDL-1             1         1,000 lb.    28½" x 42 /8" x 31¼"  227
                                                                                               5
                                             FMDL-2             2         2,000 lb.    41¼" x 42 /8" x 31¼"  311
                                             WITH ROLLERS
                                             FMDL-1-LDS-R3       1         1,000 lb.    28½" x 46½" x 31 /4"  227
                                                                                                    1
                                             FMDL-2-LDS-R3       2         2,000 lb.    44 /8" x 46½" x 31¼"  311
                                                                                         7
            model FMDL-2
                                             WITH BELT
                                             FMDL-1-LDS-B1       1         1,000 lb.    28½" x 44 /8" x 31 /4"  227
                                                                                               5
                                                                                                    1
                                             FMDL-2-LDS-B1       2         2,000 lb.   45 /16" x 44 /8" x 31 /4"  311
                                                                                               5
                                                                                         5
                                                                                                    1
                                             LDS-R3         OPTIONAL LIFTING DRUM SADDLE ROLLER STYLE      24
                                             LDS-B1         OPTIONAL LIFTING DRUM SADDLE BELT STYLE        21
                  ROLLERS          BELT
                                            Fork Mounted Drum Lifters
                  Suffix LDS-R3    Suffix LDS-B1
                                            Fork truck attachments utilize a single automatic clamping mechanism for handling any size steel,
                                            plastic, or fiber chimed drum. Scales available, contact factory.
                                            Model FMDL-850 is a knockdown unit that bolts together. Fork pockets and safety chain provide
                                            quick and easy installation.
                                            Model FMDDL-1700 can lift two drums.  It attaches to fork trucks and walkie stackers.
                                            The following are fork mounted drum lifters that enable fork truck operators to install or remove
                                            the attachment in seconds without any tools. Totally enclosed fork pockets with attached safety
              model FMDL-850  model FMDL-1500
                                            chain and cam lock secures the attachment to the fork truck.
                                            Models FMDL-1500 & FMDL-2000 - Fork truck attachments utilize a heavy-duty single
                                            automatic clamping mechanism for handling steel, fiber, and plastic chimed drums in high
                                            volume applications.
                                            Models FMDDL-3000 & FMDDL-4000 feature heavy-duty double articulating clamping
                                            mechanisms for handling any steel, plastic, or fiber chimed drums in high volume applications.
                                            Each drum is gripped with two (2) upper and lower jaws in heads that are spaced about 6" apart.
              model FMDL-2000  model FMDDL-3000
                                                MODEL             ACCEPTABLE         UNIFORM   OVERALL SIZE  WEIGHT
                                                NUMBER            DRUM TYPES         CAPACITY   ( W x L x H)  (POUND)
                                             FMDL-850*     (1) STEEL, PLASTIC OR FIBER  750 lb.  31" x 34" x 35"  170
                                             FMDL-1500     (1) STEEL, PLASTIC OR FIBER  1,500 lb.  33" x 47" x 37"  340
                                             FMDL-2000     (1) STEEL, PLASTIC OR FIBER  2,000 lb.  33" x 47" x 37"  366
                                             FMDDL-1700*   (2) STEEL, PLASTIC OR FIBER  1,500 lb.  38" x 34" x 35"  240
                                             FMDDL-3000    (2) STEEL, PLASTIC OR FIBER  3,000 lb.  33" x 47" x 37"  432
                                             FMDDL-4000    (2) STEEL, PLASTIC OR FIBER  4,000 lb.  33" x 47" x 37"  482
              model FMDDL-4000
                                            *LIGHT-DUTY UNIT TO HANDLE 100 OR FEWER DRUMS PER MONTH
                                            Horizontal Drum Carrier
                                            Designed exclusively for lifting closed and open-head steel drums with a secured lid installed.
                                            Used to load and unload steel drums horizontally in racks.  Safety restraint secures cradle to the
                                            forks to maximize safety and productivity. Drum lock engages and disengages automatically as a
                                            function of the fork angle. Fork pockets measure 7 /8" wide by 2 /8" high usable.
                                                                               5
                                                                                         5
            model HORIZ-70                      MODEL           ACCEPTABLE              UNIFORM          WEIGHT
                                               NUMBER            DRUM SIZE              CAPACITY         (POUND)
                                             HORIZ-70           55 GALLON                650 lb.          161
                                            Horizontal Drum Positioner
                                            Ideal for loading/unloading drums stored horizontally on drum racking and stands.  Suitable
                                            for loading drums onto vehicles.  Fork opening is 24½" apart and fork pockets are 5½" x 2".
                                            Accommodates 22½" diameter by 36" high steel, plastic, and fiber drums.

                                                MODEL        ACCEPTABLE      OVERALL SIZE    UNIFORM     WEIGHT
                                               NUMBER        DRUM SIZE        (W x L x H)    CAPACITY    (POUND)
            model HDT-500
                                             HDT-500       55 GALLON      29" x 55½" x 4¾"  650 lb.      115
