Page 10 - Industrial & Commercial Ladders
P. 10

239
          Tank Access Ladders

          The NTAL Tank Access Ladders have a unique modular design for inspecting storage tanks.
          The rungs are offset to protect knuckles and are made from non-slip steel material. This ladder
          has a durable welded steel construction and a baked-in powder-coated toughness.  Models
          with 10 to 15 rungs ship knockdown.

             MODEL      OVERALL     NUMBER      OVERALL      USABLE    WEIGHT
             NUMBER    HEIGHT (FT.)  OF RUNGS    WIDTH       WIDTH     (POUND)
           NTAL-7          7           7          14"         13"       69
           NTAL-10        10          10          14"         13"       128
           NTAL-12        12          12          14"         13"       138
           NTAL-15        15          15          14"         13"       148
                                                                                model NTAL-7                       INDUSTRIAL & COMMERCIAL LADDERS




          Walk-Thru Style Dock Ladders
          Prevent needless dock injuries with Walk-Thru Style Dock Ladders. Constructed of steel pipe.
          Mount ladder directly to the dock face by either welding or bolting on. The top half of each
          step is covered with a slip resistant material for extra safety during climbing and descending of
          the ladder.  The extra high handrail provides maximum assistance and safety. All ladders project
          8⅜" out from face of dock.  Models with 5 - 10 steps ship knockdown. Some assembly required.
          Baked-in powder-coated toughness.
            MODEL      OVERALL    NUMBER   TOP STEP  WIDTH    DISTANCE  WEIGHT
            NUMBER    SIZE (W x H)  OF RUNGS  HEIGHT  OF STEP  BETWEEN STEP  (POUND)
           DKL-2    20 /16" x 65½"  2       15"      18"       12"       86
                      7
           DKL-3    20 /16" x 77½"  3       27"      18"       12"       89
                      7
           DKL-4    20 /16" x 89½"  4       39"      18"       12"       92                       model DKL-4
                      7
           DKL-5    20 /16" x 101½"  5      51"      18"       12"       96
                      7
           DKL-6    20 /16" x 113½"  6      63"      18"       12"       98
                      7
           DKL-7    20 /16" x 125½"  7      75"      18"       12"      118
                      7
           DKL-8    20 /16" x 137½"  8      87"      18"       12"      121
                      7
           DKL-9    20 /16" x 149½"  9      99"      18"       12"      123
                      7
           DKL-10   20 /16" x 161½"  10     111"     18"       12"      148
                      7
          Aluminum Telescopic Ladders
          Ideal when storage space is limited. The lightweight and low
          profile design allows for storage in closets or tight spaces.
          Each step is serrated and has a spring loaded locking pin
          that automatically engages to secure step height. The release
          mechanism provides a smooth automatic closing design.
          These ladders extend in 12" increments. Top bumper guards
          and molded rubber feet protect walls and floors against
          scratches. Meets OSHA and ANSI specifications.  model TLAD-10  model TLAD-12  model TLAD-12-1A  model TLAD-15-1


              MODEL       TOP STEP    CLOSED SIZE   STEP    UNIFORM   WEIGHT
              NUMBER      HEIGHT       (W x D x H)  DEPTH   CAPACITY  (POUND)
           TLAD-10�     6 in. - 10 ft.  18½" x 2¾" x 29"  1½"  225 lb.  24
           TLAD-12�     6 in. - 12 ft.  19¼" x 3½" x 32"  1½"  225 lb.  30
           TLAD-12-1A   6 in. - 12 ft.  18" x 4" x 32"  1½"  300 lb.    36
           TLAD-15-1    6 in. - 15 ft.  19" x 4" x 36"  1½"  250 lb.    40
   5   6   7   8   9   10   11   12   13   14   15
