Page 8 - Industrial Carts & Dollies
P. 8

343
          Fold-Up Aluminum Platform Truck

          Telescoping aluminum frame has dual length platform; 25" extended and 16½" retracted.
          Easy steering with 4" x 1" hard rubber casters, two (2) rigid and two (2) swivel. Folded
          dimensions are 16"W x 20"L allowing the truck to fit into tight spaces for storage. Handle
          height is 33½" extended and 26½" retracted. Ideal for delivery, repair personnel, frequent
          travelers, and salespeople.
                                                                                    model
                                                                                    FAPT-1628
              MODEL        OVERALL    DECK   UNIFORM STATIC               WEIGHT
              NUMBER      SIZE (W x L)  HEIGHT  CAPACITY    CASTER TYPE   (POUND)
           FAPT-1628     16" x 28"    6½"      300 lb.   HARD RUBBER      18




          Flat Bed Cart                                                                                            INDUSTRIAL/COMMERCIAL CARTS & DOLLIES
          Heavy duty steel platform cart provides long term service.  Removable handle. Rolls on four (4)
          5" swivel and two (2) 8" poly rigid casters.  Center caster provides great maneuverability.  Ideal for
          industrial, commercial, and warehouse use.
                                                                                    model
                                                                                    FLAT-C
              MODEL        DECK SIZE     UNIFORM STATIC                  WEIGHT
             NUMBER        (W x L x H)     CAPACITY       CASTER TYPE    (POUND)
           FLAT-C      30" x 60" x 11¾"   2,000 lb.   POLYURETHANE       162




          Stainless Steel Platform Trucks
          High quality Stainless Steel Platform Trucks are highly suited for clean room environments,
          applications with food handling, and pharmaceutical industry.  Completely formed from 201 grade
          stainless steel sheet and tube.  Corrosion resistant, non-wearing, temperature resistant, completely
          hygienic, and stainless steel roller bearings.  100% stainless steel platform trucks.  model
                                                                                    SSPT-3048
              MODEL     DECK SIZE   DECK    UNIFORM STATIC                WEIGHT
              NUMBER     (W x L)   HEIGHT      CAPACITY     CASTER TYPE  (POUND)
           SSPT-2436   24" x 36"   9½"       2,000 lb.    POLY-ON-POLY    65
           SSPT-2448   24" x 48"   9½"       2,000 lb.    POLY-ON-POLY    74
           SSPT-3048   30" x 48"   9½"       2,000 lb.    POLY-ON-POLY    80
           SSPT-3060   30" x 60"   9½"       2,000 lb.    POLY-ON-POLY    106
           SSPT-3672   36" x 72"   9½"       2,000 lb.    POLY-ON-POLY    125



          Steel Platform Trucks
          Solid, smooth steel deck is all welded and features structural reinforcement underneath for extra   model
          strength.  Includes one removable steel handle and rolls smoothly on two (2) rigid and two (2)   SPT-3060
          swivel casters.  Series SPT comes standard with a floor lock, chrome plated handle, and baked-in
          powder-coated toughness.


               MODEL      DECK SIZE   DECK     UNIFORM STATIC   CASTER    WEIGHT
              NUMBER       (W x L)   HEIGHT      CAPACITY     SIZE / TYPE  (POUND)
           STEEL PLATFORM TRUCKS
           SPT-2448       24" x 48"  11 /16"     3,600 lb.   8" x 2" GFN*  197
                                       11
           SPT-3060       30" x 60"  11 /16"     3,600 lb.   8" x 2" GFN*  229
                                       11
           SPT-3672       36" x 72"  11 /16"     3,600 lb.   8" x 2" GFN*  265
                                       11
                                                                                                       model
                                       7
           ECSPT-2448    24" x 48"   11 /8"     2,000 lb.  6" x 2" RUBBER  125                        ECSPT-2448
           STEEL PLATFORM TRUCKS WITH SCALE
           SPT-2448-SCL   24" x 48"   15 /16"    3,600 lb.   8" x 2" GFN*  375
                                       1
           SPT-3060-SCL   30" x 60"   15 /16"    3,600 lb.   8" x 2" GFN*  463
                                       1
           SPT-3672-SCL   36" x 72"   15 /16"    3,600 lb.   8" x 2" GFN*  569
                                       1
           WRITING TABLE
           WT-TBL       WRITING TABLE measures 10½"W x 13 / 16"H with a 1" lip  7
                                                   9
          *GLASS-FILLED NYLON
           CASTERS MAY NOT BE
              ATTACHED FOR                                                                            model
                                                                                                      SPT-2448-SCL
            SHIPPING PURPOSES
                                                                   model WT-TBL
